How to make 8-bit sound effects with the Web Audio API

Before we start, find the little speaker icon in the header and click it.

Go on. I'll wait.

Did you hear that? Four notes, climbing up a C major chord, like you just found a secret in a Zelda dungeon. Now hover over the links in the nav. Tick, tick, tick. Open a photo in the gallery and you'll hear a camera shutter. Like this post ten times and... well, you'll see.

Here's the fun part: every one of those sounds is built from scratch in your browser, a few milliseconds before you hear it, using the same trick the Nintendo Entertainment System used in 1985.

I'm an amateur musician: I've played bass in the worship band for 10 years, I was a drum major in high school, and I've played trumpet since the third grade. That's enough music theory to get me into this, and not always enough to get me out.

Let's take it apart. Along the way you'll find little machines to play with. Each one has a Play button that works even with the site's sounds off, since pressing Play is asking for sound.

The Web Audio API in five lines

Every browser ships a synthesizer, and almost nobody uses it. It's called the Web Audio API, and its mental model is a bunch of guitar pedals connected by cables.

You make nodes. You plug them into each other. The last one plugs into your speakers.

// The audio engine. Everything plugs into this.
const audio = new AudioContext()

// A tone maker and a volume knob
const oscillator = audio.createOscillator()
const gain = audio.createGain()

// Tone into the knob, knob into your speakers
oscillator.connect(gain).connect(audio.destination)

// Start the tone (and never stop it)
oscillator.start()

Run that in your console and you'll get a tone that never stops. (Close the tab. It's fine. I've done it too.) Or skip the console and press Play here. This one has a Stop button:

That's the whole engine. An oscillator makes a wave, a gain node turns it up or down, and the destination is the speaker. Everything else is deciding which wave, how loud, and for how long.

Why square waves sound like Nintendo

An oscillator can make four basic shapes: sine, triangle, sawtooth, and square. A sine wave is smooth and pure, like a tuning fork. A square wave snaps between "all the way up" and "all the way down" with nothing in between.

That snapping is where the buzz comes from. Back in 1807, Joseph Fourier showed that any repeating wave can be built by stacking sine waves. For a square wave, the recipe is oddly specific: take the note, then add the 3rd harmonic (three times the pitch) at 1/3 the strength, the 5th at 1/5, the 7th at 1/7, and keep going forever.

Don't take my word for it. Drag the slider:

With one harmonic, you get a sine wave: round, soft, a little boring. Each harmonic you add squares off the corners and brightens the tone. By 15 it looks (and sounds) like a square, except for those little horns at each corner. That overshoot is called the Gibbs phenomenon, and it never goes away, no matter how many harmonics you add. It just gets narrower.

Your ear hears that stack of odd harmonics as a bright, reedy, slightly obnoxious tone. In other words, it sounds exactly like 1985.

The NES had five sound channels, and two of them were square waves (Nintendo called them "pulse" channels). Mario's jump, the coin, the Zelda secret jingle: square waves. So that's what my oscillator uses:

// The buzzy NES shape, instead of the smooth default sine
oscillator.type = 'square'

// The pitch in hertz (vibrations per second). 523 is C5.
oscillator.frequency.value = 523

Slide through the formula yourself. Each step is one semitone, and every 12 steps the pitch doubles:

A sound is a list of notes

Once you can play one note, a sound effect is just a few notes in a row. So each sound on this site is a tiny score: a list of notes, played one after another.

In TypeScript, one note looks like this:

// A pitch (hertz, 'noise', or 'rest'), then how long it lasts
type Note = readonly [pitch: number | 'noise' | 'rest', seconds: number]

That's a tuple, an array with exactly two slots that each have their own type. The first slot is the pitch: a frequency in hertz, or one of two words, 'noise' for a burst of static (more on that later) or 'rest' for silence. The second slot is how long it lasts, in seconds. readonly stops any code from changing a note once it's written.

Every sound on the site lives in one object, SOUNDS. Each key is a name, and each value is a list of notes:

const SOUNDS = {
  // The chime when you turn sound on: a C major chord, one note at a time
  'sound-on': [
    [523, 0.06], // C
    [659, 0.06], // E
    [784, 0.06], // G
    [1047, 0.12], // C, an octave up, held a little longer
  ],

  // Super Mario Bros.' coin: a quick B, then a ringing E
  coin: [
    [988, 0.08], // B5
    [1319, 0.5], // E6
  ],

  // The tick when you hover a link: one D, 20 milliseconds long
  hover: [[1175, 0.02]],
} satisfies Record<string, readonly Note[]> // every entry must be a list of notes

Look at that coin sound. Two notes. A short B, then a long E. That's one of the most recognizable sounds in video games, and it's four numbers.

The hover tick is a single D6 that lasts 20 milliseconds, just long enough to hear a pitch in it. That's on purpose. You'll hear it dozens of times per visit, and anything longer gets old fast.

To play a sound, the site calls playSound() with its name, like playSound('coin'). So a new sound is one new entry in SOUNDS: write the notes, give them a name, and playSound() plays them.

That's the whole format, so I built a generator for it. Load one of the five sounds I wrote for it in the NES style, change any number, and press Play. Holding an arrow on a pitch climbs the scale one note at a time:

Try this one: load the power-up and shorten the last note from 0.3 to 0.05. Same six notes, and the ta-da turns into a blip. Half of what makes a sound feel like a reward is how long it rings.

The code under the generator is the same kind of list as every entry in SOUNDS. Make something you like, add it to SOUNDS under a name, and TypeScript checks every note before it ever plays.

Scheduling notes on the audio clock

Here's the function that turns a list of notes into sound, trimmed a little. Every sound effect on the site ends up here:

export function playNotes(notes: readonly Note[], options: PlayOptions = {}) {
  // No Web Audio in this browser? Play nothing.
  const audio = getContext()
  if (!audio) return

  // The first note starts right now, on the audio clock
  let start = audio.currentTime

  for (const [pitch, seconds] of notes) {
    // A rest makes no sound. It only moves the clock forward.
    if (pitch !== 'rest') {
      // A square wave, or noise
      const source = createSource(audio, pitch, options)

      // This note's own volume knob, faded out over the note
      const gain = audio.createGain()
      gain.gain.setValueAtTime(VOLUME, start)
      if (options.fade !== false) gain.gain.exponentialRampToValueAtTime(0.001, start + seconds)

      // Wire it to the speakers, and book when it starts and stops
      source.connect(gain).connect(options.destination ?? audio.destination)
      source.start(start)
      source.stop(start + seconds)
    }

    // The next note starts when this one ends
    start += seconds
  }
}

// The site plays sounds by name, and only after you turn sound on
export function playSound(name: SoundName) {
  if (soundEnabled()) playNotes(SOUNDS[name])
}

(The options exist for the demos in this post. The site's own sounds always use the defaults.)

There's a subtle idea in here that took me a minute to get. Notice there's no setTimeout. No await. The loop runs all at once, in well under a millisecond, and schedules every note in advance.

audio.currentTime is the audio clock, and it runs on its own thread. By the second note of the sound-on chime, start is 60 milliseconds in the future. When the loop calls source.start(start), I'm not asking JavaScript to wait 60 milliseconds. I'm handing the audio thread a note and saying "play this at exactly this time." The main thread could freeze solid right after, and the jingle would still come out perfectly in rhythm.

If you've ever tried to time animations with setTimeout and watched them drift, this should feel like a gift.

Fading each note out

Each note gets its own gain node, and the gain doesn't just stay flat. Here are the three lines from playNotes that shape it:

// A volume knob for this one note
const gain = audio.createGain()

// Full volume when the note starts...
gain.gain.setValueAtTime(VOLUME, start)

// ...sliding down to almost silent by the time it ends
gain.gain.exponentialRampToValueAtTime(0.001, start + seconds)

The knob starts at VOLUME and slides down toward silence over the length of the note. The browser does the sliding on the audio thread, so there's no loop turning it down a step at a time.

Why fade every note? Two reasons.

First, it sounds better. Real instruments don't stop dead; they decay. A little fade turns a flat beep into a plink.

Second, cutting a wave off mid-swing makes an audible click. The speaker cone is pushed out, and then suddenly it isn't. That instant jump contains a burst of every frequency at once, and your ear hears it as a click. Fading to almost nothing before stop() hides the seam.

This one is easier to hear than to read about. Both players play the same sine wave for the same length of time, but the one marked "Without fade" skips the ramp (that's fade: false in the options). Listen to the very end of each one:

I used a sine wave here on purpose. A square wave's buzz is busy enough to hide the click; a sine wave has nowhere to hide it.

And VOLUME itself is 0.05. Five percent! That felt way too low when I wrote it. Then I tried 0.3 with headphones on. Square waves are loud, because all those stacked harmonics carry a lot of energy. Five percent is plenty.

Noise, for sounds without a pitch

Not every sound is a note. When you open a photo in the gallery, you hear a camera shutter: ch-chk. There's no pitch in that. It's just a burst of hiss.

The NES had a channel for exactly this, the noise channel, which made explosions, crashing waves, and nearly every drum on the system. My version is a buffer of random numbers:

function noiseBuffer(audio: AudioContext, grit: number): AudioBuffer {
  // Each grit is built once, then reused
  const cached = noise.get(grit)
  if (cached) return cached

  // One channel, one second of samples
  const buffer = audio.createBuffer(1, audio.sampleRate, audio.sampleRate)
  const data = buffer.getChannelData(0)

  // A random value from -1 to 1, repeated `grit` samples in a row
  for (let i = 0; i < data.length; i += grit) {
    data.fill(Math.random() * 2 - 1, i, i + grit)
  }

  noise.set(grit, buffer)
  return buffer
}

A buffer is a big array of numbers between -1 and 1, one per sample. Fill it with Math.random() and you get white noise: the sound of a TV between channels.

But plain white noise sounds too smooth, too modern. So the loop steps by grit and copies each random value into that many samples in a row. The site uses a grit of 4, which cuts the effective sample rate to a quarter. That knocks off the high-frequency fizz and leaves a crunchier, chunkier hiss. It's the audio version of making pixels bigger.

Crank it and see (and hear) for yourself:

Somewhere past 16, it stops sounding like static and starts sounding like a broken robot. The NES did something similar: its noise channel had 16 preset rates, which is how one channel could play both a hi-hat and an explosion.

Then the shutter is two bursts with a gap:

// A camera shutter: the mirror flips up, then the shutter closes
shutter: [
  ['noise', 0.03], // the mirror: ch-
  ['rest', 0.06], // a beat of silence
  ['noise', 0.05], // the shutter: -chk
],

The rest doesn't play anything. It pushes the start time forward. Same idea as a rest in sheet music.

The autoplay policy

Here's the thing that will bite you if you try this:

This is the autoplay policy, and it exists because of every website in 2009 that blasted music at you the moment it loaded. We did this to ourselves.

So the context is created lazily, the first time a sound plays. That's usually a click, which the browser trusts. But here's the trap I fell into: if you turned sound on during an earlier visit, the first sound on a fresh page might be a hover tick, and hovering doesn't count as interacting. The context starts suspended and stays that way, silently swallowing every sound after it.

The fix is to ask for a resume every time:

function getContext(): AudioContext | undefined {
  // Make the audio engine the first time a sound plays
  try {
    context ??= new AudioContext()
  } catch {
    // No Web Audio in this browser
    return undefined
  }

  // Asleep? Ask it to wake up. Before your first click, the browser says no.
  if (context.state === 'suspended') context.resume().catch(() => undefined)

  return context
}

Before your first click, the browser ignores the request. After it, the context wakes up and the sound plays. And the try/catch covers browsers with no Web Audio at all. They get silence, and the page keeps working.

Sound is opt-in

The bigger rule, though, isn't technical. Sound is off until you turn it on. Nobody wants a website to start beeping at them in a quiet office or at 2 a.m. next to a sleeping partner. The speaker icon is an opt-in, and the site remembers your answer.

Where to remember it took a little thought. Every page on this site is prerendered at build time, as plain static HTML. If I stored the setting in a cookie and read it on the server, every page would have to render per request just to draw a speaker icon. That's a terrible trade.

But sound only matters after JavaScript loads. So the setting lives in localStorage, and the server always renders the toggle as "off":

const on = useSyncExternalStore(
  subscribeSound, // listen for changes, even from other tabs
  soundEnabled, // read the saved setting in the browser
  () => false, // the server always draws the "off" icon
)

useSyncExternalStore takes three things: a way to subscribe to changes, a way to read the current value in the browser, and a value to use on the server. That last () => false means the server always renders the "off" icon, React hydrates without a mismatch, and then the real saved value takes over.

The subscribe function also listens for the storage event, which fires when another tab changes localStorage. Turn sound on in one tab and every other open tab flips its icon too. I added that because I could, and then I spent five minutes toggling between two tabs, giggling.

One more wrinkle: localStorage can throw. Some private browsing modes block it entirely. So reading and writing both sit in a try/catch, and if storage is unavailable, sound just stays off. A broken beep should never break a page.

Hiding the toggle without JavaScript

If JavaScript is off, the toggle can't do anything, so it shouldn't be there. CSS has a media query for that now:

/* No JavaScript? Hide the toggle. */
@media (scripting: none) {
  .toggle {
    display: none;
  }
}

The button is hidden before the page even paints, for anyone who can't use it, and I didn't need a <noscript> hack to do it.

Hover sounds, for mice only

That tick when you hover over nav links is one of my favorite details. It's also the one most likely to get annoying, so it has rules.

Touchscreens don't really hover. When you tap a link on a phone, the browser fires pointerover too, right before the click. Without a check, every tap would play the hover tick and the click sound on top of each other: tbleep. Gross.

So the handler checks the pointer type:

function onPointerOver(event: PointerEvent<HTMLElement>) {
  // Taps fire this too, but only a mouse really hovers
  if (event.pointerType !== 'mouse') return

  // The link or button under the pointer, if any
  const control = (event.target as Element).closest('a, button')

  // Where the pointer came from
  const from = event.relatedTarget instanceof Node ? event.relatedTarget : null

  // Tick when the pointer comes in from outside, not when it crosses into an icon inside
  if (control && !control.contains(from)) playSound('hover')
}

That relatedTarget line handles a sneaky bug. pointerover bubbles, and it fires again every time your mouse crosses into a child element, like the icon inside a button. Without the check, sliding across a single link with an icon in it could tick twice. relatedTarget is where the pointer came from, so if it came from inside the same link, we stay quiet.

And there's one listener on the whole <nav>, with closest() finding which link you're on, instead of a listener on every link. Event delegation: still great, 25 years later.

The tenth like

OK, I promised you a secret.

You can like a post up to ten times. Likes one through nine play the coin sound. Number ten plays this:

// The level-clear fanfare: three climbing chords, then a big finish
fanfare: [
  [523, 0.07], [659, 0.07], [784, 0.07], [1047, 0.16], ['rest', 0.04], // up a C chord
  [698, 0.07], [880, 0.07], [1047, 0.07], [1397, 0.16], ['rest', 0.04], // up an F chord
  [784, 0.07], [988, 0.07], [1175, 0.07], [1568, 0.16], ['rest', 0.06], // up a G chord

  [1047, 0.09], [1047, 0.09], [1047, 0.09], [2093, 0.7], // ta-ta-ta-TAAA
],

Three rising arpeggios (C, F, G, the I-IV-V that powers half of all pop music), then three quick Cs and one big one held for most of a second. It's a level-clear fanfare. You beat the blog. Congratulations.

Want to hear it for yourself? Find the heart that's waving at you and click it ten times.

Bonus: playing whole songs

The fanfare is 16 notes and a few rests, and it's over in about two seconds. So what would it take to play a whole song?

A four-channel sequencer

Two things change. First, NES music plays four of those five channels at once: two pulse waves, a triangle, and the noise channel. One list of notes in a row can't do that. Second, a song loops, so it can't book every note up front the way playNotes does.

So songs get written the way chiptune composers write them today, in a tracker. Each channel is a lane, and each bar is 16 steps. A note name starts a note, - holds it, and . is silence:

// Each string is one bar of 16 steps
pulse1: ['E5 . G5 . C6 - - G5 . E5 . G5 A5 - G5 .', ...], // the melody

triangle: ['C3 - . C3 G2 - . G2 C3 - . C3 G2 - C3 .', ...], // the bass

noise: ['k . h . s . h . k . h k s . h .', ...], // k = kick, h = hi-hat, s = snare

Then a sequencer walks the steps. It uses the same audio clock as before, but it only books notes a little at a time:

export function startSequencer(audio, stepSeconds, onStep) {
  let step = 0

  // Start a hair in the future, so the first note isn't late
  let time = audio.currentTime + 0.05

  function tick() {
    // Book every step that starts in the next 150 ms
    while (time < audio.currentTime + LOOKAHEAD) {
      onStep(step, time) // play this step's notes at this exact time
      time += stepSeconds(step) // then move to the next step
      step++
    }
  }

  tick()

  // Wake up every 25 ms to book a little more
  const timer = setInterval(tick, TICK_MS)

  // Call this to stop the song
  return () => clearInterval(timer)
}

Every 25 milliseconds, a timer wakes up and books whatever falls in the next 150. The timer is sloppy, and that's fine, because it never decides when a note plays. The audio clock does. The timer only has to show up before the music runs out. Chris Wilson's A Tale of Two Clocks is the classic write-up of this trick.

stepSeconds also runs again for every step, so each step can have its own length. Hang on to that. It comes back in the lo-fi section.

This player builds a song the way a band does. It starts with just the drums. Every two bars another part comes in: the bass, then the rhythm part, then the melody on top. (As the bass player, I'd like it noted that without us, songs don't sound quite right!) Flip a switch any time to take a part out or put it back.

The drums alone are the same crunchy hiss as the camera shutter, at three grits: chunky for the kick, crunchy for the snare, and fine for the hi-hat. The bass turns that into a groove. By the time the melody shows up, you've heard every part come in on its own, which you never get to do while playing the actual game.

The two pulse channels sound different on purpose. The NES could make each one high for 12.5%, 25%, 50%, or 75% of every cycle, and the narrower the pulse, the thinner and more nasal it sounds. The melody plays at 25%, and the rhythm part plays at 12.5% so it stays out of the melody's way. There's no type: 'pulse', so each one is a PeriodicWave built from the pulse's harmonics, the same way the square wave demo builds a square.

Making it lo-fi

Lo-fi goes the other direction. It takes clean audio and wears it out on purpose: muffle the top end like an old speaker, bend the pitch like a stretched cassette, and lay record crackle over the top.

Each of those is a Web Audio node. The muffling is a BiquadFilterNode set to lowpass. The crackle is a three-second noise buffer, mostly quiet hiss with a pop every so often, set to loop. The tape wobble is my favorite, because it plugs one node into another node's knob:

// A wave far too slow to hear: about one wobble every two seconds
const wobble = audio.createOscillator()
wobble.frequency.value = 0.45

// How far it bends the pitch, in cents (the lo-fi knob sets this)
const depth = audio.createGain()
depth.gain.value = 14
wobble.connect(depth)

// Plug the wobble into the pitch knob of every note
depth.connect(oscillator.detune)

An oscillator running at 0.45 Hz is way too slow to hear. But detune is an AudioParam, and you can connect a node's output straight into it. Now that slow wave pushes the pitch of every note up and down by 14 cents at the knob's starting spot (a cent is a hundredth of a semitone). That's the warble of a tape that's been left in a hot car.

Remember stepSeconds? Here's why it takes the step number. Lo-fi swings: in each pair of sixteenth notes, the first lasts a little longer and the second a little shorter. Swing is one line:

// Even steps run a little long, odd steps a little short
return straight * (step % 2 === 0 ? 1 + track.swing : 1 - track.swing)

Put it all together and you get a tape deck. It plays the same four channels as the jukebox, as if someone taped the game's music off the TV in 1986 and left the cassette on the dashboard. The first track is a lazy groove for World 1-1. The second rains on the warp pipes, with a rim click where the snare would be. The third is a sunset after you finally beat World 8-4, with a bass that jumps octaves. The lo-fi knob runs the filter, the wobble, and the crackle together:

Drag the knob to 0 and it sounds like the cartridge. Drag it to 100 and the filter closes down to 600 Hz, which is about where the music goes underwater.

What I'd tell you before you try this

A few things I learned the hard way:

• Keep them short. Almost every sound here is under a quarter of a second. Anything longer starts to feel like it's in the way.
• Keep them quiet. Start lower than you think. Then go lower.
• Make them optional. Off by default, easy to turn off, remembered.
• Pair them with something you can see. Every sound here goes with a visual change, so nobody misses information because their sound is off.
• Have fun with it. The whole point is a little bit of joy on a page that didn't need any. Pick sounds that make you smile.

The site's sound engine is about 250 lines of TypeScript with no dependencies, in components/islands/sounds.ts. The sequencer behind the songs is in components/islands/sequencer.ts.

Now go hover over some links. Tick, tick, tick.
